Mizuki Gakko

Anionic Resin

Pure Ion AX-7000

is a high-capacity premium grade bead form conventional gel polystyrene sulfonate. This resin is ideal for use in industrial or household water conditioning equipment. It possesses similar acidity levels to inorganic acids like sulfuric acid (H2SO4) and hydrochloric acid (HCl). The resin can function as an ion exchanger in alkaline, neutral, and acidic environments, showcasing rapid exchange capability and strong physical durability.

Typical Physical and Chemical Properties

Item	Specifications
Polymer Matrix Structure	Crosslinked polystyrene divinylbenzene
Physical Form and Appearance	Spherical beads
Functional Groups	[-N(CH3)3OH]
Ionic Form (as shipped)	Cl-
Total Capacity (Cl- form, wet, volumetric)	≥1.4 eq/l
Moisture Retention (Cl- form)	42-48%
Particle Size Range	0,3 mm - 1,2 mm
<0.3 mm particles (max.)	1%
Uniformity Coefficient (max.)	1.6
Effective Size	0.4 mm - 0.7 mm
Reversible Swelling (Cl- → OH-)	18%-25%
Shipping Weight (approx.)	670-730 g/L
Specific Gravity (wet Cl- Form)	1.09
pH Range (Stability)	0-14

Suggested Operating Condition

Item	Specifications
Maximum Temperature (OH- Form)	60°C max.
Maximum Temperature (Cl- Form)	80°C max.
Backwash Rate	50-75% bed expansion
NaOH Regenerant Concentration	2-4% NaOH
Regenerant Dosage	Resin Volume = 3:1
Regenerant Flow Rate	2 to 4 BV/h
Regenerant Contact Time	At least 60 minutes
Service Flow Rate	10-25 m³/h
